Dual Flow Low Speed Tandem Air, Hydraulic Oil Rotary Joints
Dual Passage Tandem Rotary Joints is a Combination Of Two Joints to Prevent Cross Contamination and Suitable For Multi Media like Air, Vacuum And Hydraulic Oil
The Type-MSU80 is tandem rotary union for transfer of media like airlvaccuum and Hydraulic, brake fluid. Pair of Bearings for alignment of rotor with housing. Self supported rotary union with aluminium housing and stainless steel rotor. Single and Two passage rotary union combine to form tandem rotary union. This equipment is manufactured by using premium raw materials. No inter passage leakage on dual flow design.
Tandem Low Speed Air, Hydraulic, Brake Fluid Dual Passage Joints
MSU80 Rotary Joints
- Tandem or triple flow design
- Rotating union is self-supported
- Axial housing connection
- Hardened Sealing surfaces
- Special Seals
- Ball bearings lubricated for life
- Composite Bearing
- Low torque and weight optimised design
- Aluminium housing; stainless steel or carbon steel rotor, depending on model
| Elastomer | Viton, EPDM, NBR, |
| MOC | SS 316, Carbon Steel, Aluminium |
| Bearing | Composite Bronze Bearing, Ball Bearing |
| Size | 1/4″ (DN08) |
| Media | : Air, Vacuum, Hydraulic oil, Brake fluid |
| Max.Air Pressure | : 10 bar |
| Max. Vacuum | : 7 kPa |
| Max. Hydraulic Pressure | : 210 bar |
| Max. Brake fluid Pressure | : 207 bar |
| Max. Temperature | : 120°C |
| Max. Speed | : 250 rpm |
Do Not Work With Maximum Pressure At Maximum Speed.
- Threaded Rotor Mono Flow And Dual Flow
- Quick Release Rotor Mono Flow And Dual Flow
- Flanged Rotor Mono Flow And Dual Flow
- Oil And Gas
- Plastics
- Agriculture And Construction
- Food And Medical
- Chemical
- Hydro Power
- Printing And Packaging
- Tire And Rubber
“Deublin” 2117 series
“Rototech” 6000 series
“Rotofluid” 600+1 series
“Rotoflux” M series
“Fourwent” FDU TAN 2100 series
