MULTI SPRING UNBALANCED MECHANICAL SEALS
031U/W32U Pusher Type Unbalanced Multi Spring Seals Designed For Chemical Pumps, Vertical Screw Pumps and Gear wheel feed pumps
We are a highly esteemed General Purpose Multi Spring Unbalanced Seal. Their Compact Design permits their use in all types of Centrifugal Pumps. All Components are held together by a Snap Ring that helps in easier installation & removal. this kind is widely used in various industries for different applications such as rotating equipment, pumps, mixers, agitators and compressors.
Unbalanced Mechanical Seals
Multi Spring Unbalance Seals is pusher type unbalanced seals used to avoid distortion at high speeds and ensure uniform pressure on seal faces under all operating conditions and Prevents any kind of leakage.
Multi Spring unbalanced seals can be easily assemble or dismantled through circlip provided and can be change to balance version by changing only the seal ring and the secondary seal.
Multi Spring unbalanced Mechanical seals are compact in design suiting all types of rotating equipments, pumps, mixers,agitators and compressors.
- Multiple Spring Mechanical Seal
- For Plain shaft
- Single acting
- Unbalanced
- Inside mounted
- Independent of direction of rotation.
| Seal Ring Face | : Carbon, Silicon, TC |
| Mating Ring Face | : Silicon, TC |
| Secondary Seals | : Viton / PTFE / GFT |
| Metal Parts | : SS 316,SS 304, Alloy 20, |
| Pressure | : 10 bars (Max) |
| Temperature | : (-)50c to (+)280c |
| Speed | : 25 m/s |
| Size | : 10 mm to 150 mm |
Generally used for handling highly corrosive chemicals, high temperature applications and Hydrocarbons In Petrochemical industry, petroleum refinery , Paper & Pulp industry
| Item No | Description |
|---|---|
| 1 | Seal Ring |
| 2 | Mating Ring |
| 4.1 | O-Ring |
| 4.2 | O-Ring |
| 6.1 | Wedge |
| 6.2 | Square Packing |
| 10 | Spring |
| 12 | Grub Screw |
| 15 | Thrust Ring |
| 17 | Retainer |
